Indian carbonization paint removal furnace
Introduction to Production Line
The continuous charcoal making machine, machine also named continuous pyrolysis furnace is a new type of machine that feeds raw materials and outputs finished materials at the same time. It belongs to an external heating drying and carbonization integrated machine.The flue gas generated in the entire production process is self-utilized, and the exhaust gas passes through the flue gas treatment device.Processing, does not pollute the environment, after technical improvement, the furnace can also be used to recycle and process electronic waste, and realize the recycling of metals and pyrolysis the plastic into carbon, realizing the sorting of metal and plastic.
Indian aluminum-plastic sorting equipment production line
Introduction to Production Line
The aluminum and plastic materials firstly crushed by the knife crusher into 10mm pieces, and then grinding by the water cooling turbo type grinding machine into aluminum and plastic fine powders. Then separated by the rotary screen, the big size will back into the grinding machine and the fine powders will into the electrostatic separator, finally the aluminum and plastic would be separated.
India customer visited our factory for Aluminum Plastic Crushine Separating Plant. He visited several suppliers during his tour in China and compared the aluminum powder separated from our system with those of other suppliers. He is quite satisfied with our equipment.
Bangladeshi customers inspect aluminum plastic recycling equipment
Introduction to Production Line
It is an important milestone when customers from Bangladesh come to inspect the aluminum-plastic sorting equipment project. The goal of this project is to implement an efficient aluminum-plastic sorting system to help customers process large amounts of waste aluminum-plastic composite materials and separate them into aluminum and plastic materials for reuse or recycling. The success of this project will help improve waste management and circular economy development in Bangladesh.
Production Line Principles
Customer visits are an important opportunity for them to see first-hand the operation and performance of the equipment to ensure it meets their needs and requirements. They can observe the equipment’s sorting efficiency, throughput, and quality control, as well as safety during operation. In addition, they can meet face-to-face with vendors and technical teams to ask questions and discuss solutions.
Paint removal equipment for cans
Paint removal equipment for cans
1.2*11.6m
400-1500kg/h
32-55kw
Product Introduction
The continuous charcoal making machine, machine also named continuous pyrolysis furnace is a new type of machine that feeds raw materials and outputs finished materials at the same time. It belongs to an external heating drying and carbonization integrated machine.The flue gas generated in the entire production process is self-utilized, and the exhaust gas passes through the flue gas treatment device.Processing, does not pollute the environment, after technical improvement, the furnace can also be used to recycle and process electronic waste, and realize the recycling of metals and pyrolysis the plastic into carbon, realizing the sorting of metal and plastic.
1.Metal recycling: aluminum capacitor recycling, circuit board recycling, waste wire recycling 2.Biomass carbonization: carbonization of biological wastes such as coconut shell, palm shell, hemp,sawdust and so on. 3.Recycling waste clothes to make carbon powder particles
Main machines::
Biomass particles or e-waste with a particle size of less than 50mm and a moisture content of less than 20% can be directly entered into the first-type machine for carbonization.
For example, sawdust, coconut shells, fruit shells, palm shells, etc. can be directly carbonized;
larger (50mm or more) raw materials, such as aluminum capacitors, wires, waste clothes, wood branches, etc.,need to be shredded and then carbonized;
if the moisture exceeds 30%, it needs to be dried in advance.
Biomass smelting furnace
Biomass smelting furnace
3.5*3*0.8m
100-200kg/h
1kw
Product Introduction
The Aluminum Ingot Melting Furnace is eco-friendly machine, which use the biomass pellet for the melting of the furnace, no need for the gas or electricity, for process one ton alu ingot only needs about 200kg wood pellet, this way shrink a lot cost . and no pollution .
We have Biomass pellet burning type heating method and gas supply heating method. Biomass pellet burning pellet is much popular. Make full use of biomass waste, high heat value, the temperature can reaches 1200℃.Energy saving, for 1T aluminum melting,
Main machines::
The furnace adopts imported high grade refractory insulation materials. coupled with high density heat insulation board. so that the surface heat loss and heat radiation area of the furnace body is reduced. the surface temperature of the furnace body is about 45C, effectively achieve energy saving and stable quality of aluminum soup, improve the high temperature working environment. The crucible adopts is ostatic pressure graphite crucible, which has fast heat conduction and long service life. The furnace is easy to feed. easy to operate and maintain. suitable for smal and medium- sized aluminum processinc enterprises.
Aluminum powder compactor
Aluminum powder compactor
15-45*2Kw
3140 Ton
32-45 Kg
5 Block/Min
Product Introduction
Aluminum Powder Compressing Machinery Metal Scrap Compactor is suitable for briquetting of various powders and scraps, such as iron powder,particle steel, refined iron powder, steel slag, Waste aluminum: aluminum powder, alloy scrap, bottle cap, Waste copper: copper powder, copper particles.
The pressed metal blocks can reduce the transportation and smelting costs,and can also improve the furnace throwing speed. Our briquetting machines have different models, and their output and shape are also different. In order to facilitate your transportation and reprocessing of materials, you can consult online or leave a message to us if you have any questions, and we will contact you in time.
Main machines::
Aluminum Powder Compressing Machinery Metal Scrap Compactor is designed with quick speed cylinder and liquid rinsing valves, and the machine has auto charging unit which can be operated by one person.
The machine uses standard materials, through product testing.
There are no loss material loss after the process.
Aluminum Powder Compressing Machinery Metal Scrap Compactor is easy to operate, saving labor.
Horizontal can pressing machine
Horizontal can pressing machine
600-1200kg/h
240-500mm
2.2-5.5kw
2800-7000kg
Product Introduction
Our waste scrap metal packing machine is used to press scrap metal(steel copper, aluminum, stainless steel,etc) into metal block or metal bale. The purpose is to save the transportation cost or reduce the raw material loss when smelting.
Our waste scrap metal packing machine is used to press scrap metal(steel,copper, aluminum, stainless steel,etc) into metal block or metal bale. The purpose is to save the transportation cost or reduce the raw material loss when smelting.
Main machines::
1) Hydraulic drive, compact design, great sealing.
2) Customized press box size and bale size.
3) Bale dischargeing ways include turn-out, side- push out and forward-out.
4) Designed with quick unit that can improve work efficiency substantially.
5) Famous motor, hydraulic system, oil cylinder, piston pump,electrical components
6) Blades: our waste scrap metal packing machine price with the knife, it can cut the long size material when compressing, so it very good for the long steel wire and big size material.
Can flattening machine
Can flattening machine
1400mm
3 times/min
30KW*2
7.5-1905T
Product Introduction
The baler machine is mainly used for compressing scrap tires, plastic, clothes.paper，carton，woven bag，textile，cotton,cotton wool，linen，clothing,wheafstraw,medicinal materials， straw, rice husk,aluminum can and other wastematerials into bales.After compressing, it is easy to transport, so save storagearea,transportation cost and labor cost，meanwhile,be beneficial to theenvironment and waste recycling. Easy operation，durable，long service life.high efficiency, energy saving and low consumption.
The baler machine is designed with vertical structure,hydraulic transmission,electrical control and manual binding.And it is a good machine to improve laborefficiency, reduce labor intensity, and reduce transport costs.
Main machines::
All models are driven by hydraulic pressure;
There are different ways of discharging materials,such as bag turning, bagpushing ( side pushing and front pushing ) or manual bag taking ( packaging ).
Installation does not require foot screws,and diesel engine can be used aspower source where there is no power source.
There are ten grades of squeezing force from 5 tons to 200 tons, which can beselected by users, and the production efficiency is from 4 tons / shift to 40 tonsshift;
The size of compression chamber and package block can be customizedaccording to customer requirements;
Aluminum plastic sorting and grinding production line
300-1000kg/h
62-170kw
7.5-1905T
Product Introduction
Our aluminum-plastic grinding production line can be used to recycle various aluminum-plastic composite materials, such as medical blisters, aluminum-plastic panels, aluminum foil, aluminum-plastic packaging bags, etc.
The aluminum and plastic materials firstly crushed by the knife crusher into 10mm pieces, and then grinding by the water cooling turbo type grinding machine into aluminum and plastic fine powders. Then separated by the rotary screen, the big size will back into the grinding machine and the fine powders will into the electrostatic separator, finally the aluminum and plastic would be separated.
Main machines::
Crusher step-shearing style cutter can resolvethe force bored by cuttings, and increase theforce of cutting greatly. Blade quality have9CrSi, Cr12MoV, SKD-l , D2 etc. Can becustomized according to customer.
New abrasive disk design, high capacitygood Wear Resistance, the service life is twotimes longer than the common abrasive disk.
Circular vibrating screen:Large Size Recyclefor Second Time Grinding. Feedback systemmakes the grind much more effective.
The negative pressure feeding systemprevent the dust from running out.
Air cooler and circulating water systemused to control temperature and reducenoise of the grinding system.
Aluminum plastic separator
Aluminum plastic separator
2000*1800*2450mm
18.5kw+3kw+0.75kw
50 m/min
2000kg
Product Introduction
A recycling machine is a specialized equipment for crushing, sorting, and recycling waste steel core aluminum stranded wires. Its main function is to separate aluminum and plastic from discarded aluminum and plastic. It has the advantages of high automation and complete separation of the aluminum layer and steel core.
The aluminum conductor steel reinforced recycling machine is a special equipment for crushing, sorting and recycling discarded steel core aluminum stranded wires. Its main function is to effectively recycle two metal resources, aluminum and steel, from discarded steel core aluminum stranded wires. It has the advantages of high degree of automation and complete separation of aluminum layer and steel core.
Main machines::
1. With professional technology and equipment, we can effectively recycle and process steel core aluminum stranded wires of different specifications. (Special 3-speed transmission for reducer)
2. The equipment and technology adopted can quickly and efficiently recycle and process steel core aluminum stranded wires. (50 meters/minute, multiple feeds available)
3. Depending on the usage scenario, electric or oil power systems can be provided.
4. According to customer needs, it can be equipped with an integrated tensioning and guiding machine, a movable ton bag rack and other supporting equipment.
5. Equipped with dust removal equipment, environmentally friendly and pollution-free.
